Arctic Cat ADAPT Drive Clutch 8 Inch 33mm for Wildcat XX - 8 Inch 33mm/DIRT-65/160

Arctic Cat ADAPT Drive Clutch is an OEM 8 inch, 33mm drive clutch for Arctic Cat Wildcat XX models. Introduced for the 2022 model year, the ADAPT clutch is designed as a lighter, more compact replacement for earlier TEAM drive clutch applications.

This clutch is 1 pound lighter than the 2021 production TEAM clutch, with a 5% reduction in inertia and a 25mm reduction in width. That compact design helps improve clutch response while reducing rotating mass in the driveline.

The clutch includes the 1646-154 65/160 lb spring installed. Cam arm weights, pins, screws, and washers are not included and must be purchased separately for the correct model, tire size, gear ratio, and altitude calibration.

Key Features

• Genuine Arctic Cat OEM ADAPT drive clutch
• 8 inch drive clutch with 33mm taper
• New ADAPT clutch design introduced for model year 2022
• 1 lb lighter than 2021 production TEAM clutch
• 5% reduction in clutch inertia
• Compact design with 25mm / 14.1% reduction in width
• Includes 1646-154 65/160 lb spring installed
• Replaces Arctic Cat part numbers 0746-970 and 0823-690

Direct Fitment

• 2022 Arctic Cat Wildcat XX late build
• 2023 Arctic Cat Wildcat XX
• 2024 Arctic Cat Wildcat XX

Conversion Fitment

This clutch can also be used to replace the 0823-690 or 0823-691 TEAM clutch originally installed on the following models:

• 2018 Arctic Cat Wildcat XX
• 2019 Arctic Cat Wildcat XX
• 2020 Arctic Cat Wildcat XX
• 2021 Arctic Cat Wildcat XX
• 2022 Arctic Cat Wildcat XX early build

For TEAM-to-ADAPT clutch conversion, remove the original drive clutch bolt washer and install the 2623-325 drive clutch spacer, sold separately. As an alternative to the spacer, Arctic Cat notes that the shorter 2623-308 drive clutch bolt may be used with the original 1623-649 drive clutch bolt washer.

Required Parts Sold Separately

• 0644-650 gold clutch puller required for clutch removal
• 8639-454 cam arm pin kit required for installation
• Cam arm weights, pins, screws, and washers required for final calibration
• Drive belt replacement is recommended when installing a new clutch

Altitude Calibration Reference

For 11.92 standard ratio with 30 inch tires or 12.47 Black Hills ratio with 32 inch tires:

• 0-4,000 ft: 1646-154 spring, 0823-736 / 0823-788 48g weights, 0823-780 35-50 degree helix, 0648-979 180-240 lb spring
• 4,000-6,000 ft: 1646-154 spring, 0823-735 46g weights, 0823-799 35-45 degree helix, 0648-979 180-240 lb spring
• 6,000-10,000 ft: 1646-154 spring, 0823-734 44g weights, 0823-799 35-45 degree helix, 0648-979 180-240 lb spring

Available ADAPT Calibration Components

• Springs: 1646-150 75/160, 1646-151 75/150, 1646-152 75/170, 1646-153 65/150, 1646-154 65/160, 1646-155 65/170
• Weights: 0823-729 34g, 0823-730 36g, 0823-731 38g, 0823-732 40g, 0823-733 42g, 0823-734 44g, 0823-735 46g, 0823-736 / 0823-788 48g
• Additional Weights: 0823-737 50g, 0823-738 52g, 0823-739 54g, 0823-740 56g, 0823-741 58g, 0823-742 60g, 0823-743 62g, 0823-744 64g

Note: This clutch does not include cam arm weights, pins, screws, washers, puller, pin kit, spacer, or belt unless stated separately in the listing.
